Rainbow Beat 2

Two Channel Amplifier Class AB

Output power stereo 4 Ω 2 x 120 Watt RMS

Output power stereo 2 Ω 2 x 180 Watt RMS

Output power mono 4 Ω 1 x 370 Watt RMS

Output power mono 2 Ω –

Output power mono 1 Ω –

Total Harmonic Distortions THD N 0,04 %

Signal / Noise Ratio 95 dBA Bewertung

Frequency Response -3 dB 25 Hz – 35 kHz

Input Sensitivity Level In 250 mV – 6 V

Input Sensitivity High Level In 6V / 10V

Auto Remote via High Level In Ja

High-pass / Subsonic 25 Hz – 5 kHz, 12 dB/Okt.

High-pass / Subsonic – Front –

High-pass / Subsonic – Rear –

Low-pass 50 Hz – 5 kHz, 12 dB/Okt.

Band-pass 25 Hz – 5 kHz, 12 dB/Okt.

Bass Boost 0 / 3 / 6 dB

Phaseshifter 0° – 180° stufenlos regelbar

Remote –

Suitable Speaker Impedance Stereo [Ω] 2 x 4 / 2 x 2 möglich

Suitable Speaker Impedance Mono [Ω] 1 x 8 / 1 x 4 möglich

Suitable Speaker Impedance Tri-Mode (Woofer Satellites) [W] 1 x 4 2 x 4 Tri-Mode

Damping Factor @ 4 Ω 200

Operational voltage 11 V – 16 V DC

Input Current max. @ 14.4 V 38 A bei 1% THD

Input Current Remote 15 mA

Idle current without signal 0,7 A

Temperature control heatsink 85°C Abschaltung

Short circuit protection – Overload Sofortabschaltung

Softstart-Muting on / off 1s Einschaltverzögerung

Dimensions (W x H x D) 241 x 56 x 200 mm
