SounDigital 800.1 EVO 5 – 4 Ohm
Power @ 2Ω: N/A
Power @ 4Ω: 800W
Power @ 8Ω: 528W
Frequency Response:
10Hz ~ 20kHz
Subsonic Filter (HP 12dB/8º):
10Hz ~ 80Hz
Low Pass Filter (LP 12dB/8º):
50Hz ~ 20kHz
Operating Voltage:
8V ~ 16V
SNR:
2Ω: 96dB
4Ω: 97dB
Input Sensitivity (RCA): 0.2V ~ 4V
Input Sensitivity (High Level input): 1.5V ~ 15V
Current Draw (Music): 4Ω: 38A
Current Draw With Resistive Load (1kHz @ 12.6V): 4Ω: 77A
Total Efficiency: 4Ω: 78%
Damping Factor (@100Hz Rated Impedance): 200
Power Cable: 10mm² (7AWG)
Audio Output Cable: 2 x 2mm² (12 AWG)
Recommended Fuse (Music): 40A
Recommended Battery (Music): 60Ah
Width: 4.4 in / 11,3 cm
Length: 5.8 in / 14,8 cm
Height: 2 in / 5,1 cm
Weight: 1.54 lb / 0,7 Kg
