Alpine R-A75M

kr3,995.00

Terminal Layout: One side
Small footprint for easy installation
Screw terminals (for speaker and power cables)
General

Amplifier Type: Class-D (Digital)
Channel Design: Mono Channel
Thermal Management Control
Top Mounted LED Power/Status Indicator
Speaker Level Input with remote turn on
Crossover: Adjustable Low-pass (LPF)
Gain Control: Adjustable
Bass EQ
Subsonic Filter
Remote Bass Control (RUX-KNOB2) Ready

Artikelnr: R-A75M Kategori:

Beskrivning

Per Channel into 2 Ohms, 14.4V (≤1%THD+N): 1 x 750W
Per Channel into 4 Ohms, 14.4V (≤1%THD+N): 1 x 500W
Sound Tuning

Crossover: Variable LPF: 50-400Hz (-24dB/oct )
Variable Subsonic: 8Hz – 40Hz (-24dB/oct.)
General

Power Requirements: 14.4 V.DC (9 – 16 V allowable)
Input Sensitivity (RCA Input): Hi: 0.4V – 10V / Low: 0.1V – 4.0V
High Level Input with automatic power on
Cable size: Power Cable AWG 4, SPK Cable AWG 8
Frequency Response (+0/ -3dB: 1W into 4 Ohms): 10Hz – 400Hz
THD+N (@ 10W into 4 Ohms): <0.02%
THD+N rated power into 4 Ohms): <0.03%
Damping Factor: >1500
Signal to Noise (rated power into 4 Ohms): >105dB
Weight: 3.2kg
Dimensions

Heat Sink (WxHxD) mm: 273 x 50.8 x 200
With attached brackets: 273 x 50.8 x 223

Mer information

Vikt7 kg
