HELIX IK E10.1-DVC2

3190.00kr

Lägsta pris senaste 30 dagarna: 3190.00kr.

Powerful bass, compact format – the performance subwoofer for everyday use

The HELIX IK E10.1 delivers deep, punchy bass in a space-saving design – ideal for those who want rich low-frequency performance without the bulk of a conventional subwoofer enclosure.

Smart downfire design

The intelligent downfire construction ensures optimal bass dispersion in the vehicle. It uses the vehicle floor as an acoustic reflection surface to intensify low-frequency output, offers optimum protection for the speaker, and allows for a lower-profile design. Combined with bass-reflex technology and a powerful 250 mm chassis, it provides a dynamic bass experience with impressive sound pressure while making efficient use of available space.

Kan restnoteras

Artikelnr: IK E10.1-DVC2 Kategori: Helix Varumärke: Helix

IK E10.1-DVC2

2 x 2 Ohms
Power handling RMS P 300 Watts
Recommended amplifier power RMS 150 – 300 Watts
Impedance 2 x 2 Ω
Max. linear excursion Xmax +/- 8.0 mm
Port tuning frequency Fb 43 Hz
Sensitivity,SPL 91 dB @ 2.83V / 1m
88 dB @ 1W / 1m

Dimensions (H x W x D)
187 x 470 x 375 mm
7.4 x 18.5 x 14.8″

Integrated subwoofer chassis HELIX IK W10-DVC2
Recommended DSP settings ″Self-define″ highpass 37 Hz / Q = 1.5
EQ filter: 115 Hz / Q = 0.7 / -2 dB
